Digital Storage Oscilloscope 60 Mhz 1GHS/s 2 channels LCD +usb. Display colori 16/9. Oscilloscopio Digitale 60Mhz ATTEN ADS 1062CAL Model Index ADS1062CAL Bandwidth 60MHZ Sampling Rate Single Channel:1000MSa/s;Double Channels:500Msa/s Equivalent Sampling Rate 50GSa/s Memory Depth Single Channel: 2M; Double Channels: 1M/CH Rise Time <5.8ns Input Impedance 1M ohm || 17pF Sec/div Range 5ns/div-50s/div Display Color TFT(320*234)5.7 LCD 16/9 Technical Specifications: The Common Specifications Of All ADS1000 Series Products Display 12 divides full screen display Channels 2 Vertical Sensitivity 2mv-5v/div(1-2-5 Sequence) Vertical Resolution 8bit Input coupling DC, AC, GND Input Max voltage 400V(Vpp) Trigger Types Edge, Pulse, Video, Slope, Alternative, Delay Trigger Modes Auto, Normal, Single Trigger Source CH1, CH2, Ext, Ext/5, AC Line Save/Recall Provide two groups reference waveforms, twenty groups capture waveforms and twenty groups setups internal save/recall function and USB flash drive Save/Recall function Auto Measure Types Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Vavg, Mean, Vrms, Crms, ROVShoot, FOVShoot, RPREShoot, FPREShoot, Freq, Period, Rise time, Fall Time, +Width, -Width, +Duty, - Duty, BWid, Phase, FRR, FRF, FFR, FFF, LRR, LRF, LFR, LFF Cursor measure Manual, Track, Auto Sample Types Real Time, Equivalent Time Averages 4, 16, 32, 64, 128, 256 Math +, -, *, /, Invert FFT Window: Hanning, Hamming, Blackman, Rectangular Sampling Points: 1024 points XY Mode Phase Error: +/-3 degrees Support the sampling rate : 5KSa/s200MSa/s (in a 1-2-5 sequence) Persist Off, 1sec, 2sec, 5sec, Infinite Display Model Main, Window, Window Zoom, Roll, X-Y Menu Display 2Sec, 5Sec, 10Sec, 20Sec, Infinite Skin Classical, Modern, Tradition, Succinct Display Language Simplified Chinese, Traditional Chinese, English, Arabic, French, German, Russian, Spanish, Portuguese, Japanese, Korean Power Source Voltage 100-240VAC, 47HZ-440HZ, 50VA Max Size and Weight 305mm x 154mm x133mm, about2.3kg USB Host Support USB flash drive storage USB Device Support PictBridge compatible printers and PC Remote control RS-232 ATTEN ADS1062CAL Digital Storage Oscilloscope Package Contains 2 proves 10:1 EasyScope Computer Software System Power Cord USB-cable User guide
